Home > 모니터 > SWM Series : Studio Wall Monitors > SWM-240A

SWM-240A

  • SWM-240A
  • SWM-240A
  • SWM-240A



SWM

Audio Level Meter Display

Audio Level Meter Display

Displays the level of the embedded sound signal together with the video signal input through the terminal such as SDI or HDMI.

Closed caption

Closed caption

Closed caption.

Blue Only / Mono

blue only

Red and Green channels are not used and only Blue or Monochrome channel is used to display the screen. This function is used to adjust the color tones (tones and saturation) of the screen using the SMPTE Color Bar. For example, after displaying the Blue channel, adjust the Color (or Saturation) and Tint (or Hue) so that the original Magenta and Cyan are of the same brightness, and the original Gray and Blue are of the same brightness.

H/V Delay

H/V Delay

Allows you to check the Blanking area and synchronize signals by displaying the horizontal and vertical intervals in the center of the screen.

Marker

Marker

Displays various kinds of aspect ratios on the screen. Wide range of markers and security areas are available with line color and curtain transparency selection. A User Marker is available if any of standard markers fits your requirements.

Time Code Display

Time Code Display

Displays the Timecode information on the screen.

User Aspect

User AspectUser AspectUser Aspect

Adjusts the Width /Height display ratio.

3G-SDI Level A/B

Supports 3G-SDI Level A/B input.

UMD

UMD

Displays user customized 8 characters or source ID or Tally signal of Ancillary (ANC) data on the screen.

SWM-240A : 새로운 스튜디오 월모니터.
SWM 시리즈는 스튜디오에 적절하게 사용 할 수 있도록 완전히 새롭게 디자인 된 제품입니다. 오직 상태표시등만 보이는 베젤로 이루어져 있어 사용자가 모니터를 사용할 때 최적의 효율을 보일 수 있도록 디자인 되었습니다. 가장 많이 쓰이는 SDI, HDMI, DVI 외에 Optical 신호도 추가되어 사용자가 더욱 편하게 작업 할 수 있습니다. 이 제품은 3G-SDI 또한 지원하며 Marker, Timecode, Audio Level Meter 등 다양한 전문가용 기능 등을 지원합니다.
Display Spec.
 Size  24"
 Resolution  1920 X 1200 (16 : 10)
 Pixe Pitch  0.270mm
 Color Depth  16.7M
 Viewing Angle  178°(H) / 178°(V)
 Luminance  300cd/m2
 Contrast Ratio  1000:1
 Display Area  518(H) x 324(V) mm
Input
 2 X BNC  3G-SDI A/B Channel Input
 1 X HDMI  HDMI Input
 1 X DVI  DVI Input
Output
 2 X BNC  3G-SDI Out
Audio
 Audio Out  -
FPGA Functions
,  3G-SDI Level A/B,  Audio Level Meter Display,  Blue Only,  H/V Delay,  Marker,  Mono,  Time Code Display,  UMD,  User Aspect
Closed Caption
 CC-608 ANC,  CC-608 LINE 21,  CC-708,  CC-KOR,  OP42,  OP47
Calibration
Other Functions
 USB   AUTO Calibration   Firmware update by USB cable   Firmware update by USB memory stick
 Ethernet   Ethernet Control support
 Conversion   SDI-to-SDI,
Options
  ND Acrylic Filter,  Rack Mount Kit(Single),
SWM-240A : 새로운 스튜디오 월모니터.
- Main Body : 552.5 x 389 x 95.8 (mm) / 21.75 x 15.31 x 3.77 (inch)
- Weight : 8.2 Kg


SWM-240A : 새로운 스튜디오 월모니터.
  Pronduct Brochure (1 Page)   Download
  Manual   Download
  Leaflet    -
  Total Brochure   Download
